The Problem: Electric Roller Shutters, But Not Smart
You have electric roller shutters or blinds, but still have to operate them directly at the wall switch? That’s a real shame, because an electric motor is already halfway there to a smart blind!
With a Shelly module, you can make your existing roller shutters smart and integrate them into your smart home – completely local, without any cloud dependency and surprisingly affordable.
In the new video I show you the complete implementation!
Why Shelly for Blinds?
✅ Completely Local
- No cloud connection required
- Works even during internet outages
- Your data stays with you
✅ Affordable and Flexible
- Shelly Plus 2PM: ~€20–25
- Older Shelly 2.5: Even cheaper
- Fits in any in-wall junction box
✅ Safe Installation
- Built-in safety functions
- Prevents simultaneous activation of both directions
- Calibration for precise positioning
Choosing the Right Hardware
In the video I show various Shelly models:
Note: Links marked with affiliate link are affiliate links. As an Amazon Associate I earn from qualifying purchases. This means I receive a small commission if you purchase through these links — at no extra cost to you. The revenue helps me run this blog and YouTube channel and keep creating content. Thank you for your support!
― Joachim
Recommendation: Shelly Plus 2PM
- Current successor model
- Lowest price on the market
- Perfect for blinds and roller shutters
- Shelly Plus 2PM on Amazon (paid link) ← most affordable option
Alternative: Shelly 2 Gen3
- New generation with more features
- Shelly 2 Gen3 on Amazon (paid link)
Latest Generation: Shelly 2 Gen4
- Newest version available
- Shelly 2 Gen4 on Amazon (paid link)
You can safely save money and stick with the Plus devices!
Wiring: What You Need to Watch Out For
Correct wiring is crucial! In the video I explain step by step:
Power Supply:
- Neutral wire (N) and live wire (L) from the in-wall junction box
- Connected to the corresponding terminals of the Shelly
Switch Connection:
- Route the live wire through to the wall switch
- “Up” switch and “Down” switch to S1 and S2
- Order doesn’t matter – can be changed in software later
Motor Connection:
- Outputs O1 and O2 to the roller shutter motor
- O1: Move up
- O2: Move down
- Again: order can be changed later in software
⚠️ Important: Always follow 230V electrical safety rules!
Software Setup: Safety First
1. Secure Initial Setup
In the video I show two approaches:
Recommended: Shelly App
- ✅ Uses Bluetooth (encrypted)
- ✅ More secure than hotspot
- ✅ Easy to use
Alternative: Hotspot
- ⚠️ Unencrypted
- ⚠️ Wi-Fi password can be intercepted
- ✅ Works without the app
2. Disable the Cloud
Important for local use:
- Set Cloud Settings to “Disabled”
- Set Server to “Disconnected”
- Why? Complete local control
3. Device Profile: The Critical Setting
You absolutely must configure this:
Settings → Device Profile → “Cover”
Why is this so important?
- Prevents simultaneous activation of both outputs
- Without this setting: Motor damage is possible!
- Shelly then “knows” it’s controlling a roller shutter
Calibration and Fine-Tuning
Check Directions
After the initial setup:
- Test the buttons on the web interface
- Wrong direction? → Enable Reverse Directions
- Check wall switch → Enable Swap Inputs if needed
Calibration Run
Enables precise positioning:
What happens:
- Roller shutter moves completely down
- Then completely up
- Stops at various intermediate positions
- Result: Any position can be precisely controlled
In the video you can see the entire process live!
Home Assistant Integration
Automatic Discovery
It’s this easy:
- Install the Shelly Integration in Home Assistant
- New devices are discovered automatically
- One click → Integration complete
Dashboard and Automations
After integration:
- ✅ Display roller shutters on the dashboard
- ✅ Create automations:
- Automatic opening/closing
- Sun protection during intense sunlight
- Time-based schedules
Tip: I’ll show more blind automations in Home Assistant in an upcoming video!
Practical Benefits in Daily Life
Convenience
- App control from anywhere in the home
- Automation based on time of day
- Scenes for different situations
Security
- Presence simulation while on vacation
- Automatic closing during storms
- Integration into a security system
Energy Efficiency
- Intelligent sun protection reduces cooling costs
- Heat retention in winter by closing at the right time
- Light optimization through precise positioning
Cost-Benefit Analysis
Investment:
- Shelly Plus 2PM: ~€20–25
- Installation: DIY-friendly with basic knowledge
- Ongoing costs: None (local solution)
Alternative: Ready-Made Smart Blinds
- Cost: €200–500+ per roller shutter
- Cloud dependency: Usually required
- Flexibility: Tied to the manufacturer
Conclusion: The Shelly solution is significantly cheaper and more flexible!
Avoiding Common Mistakes
❌ Forgetting the Device Profile
Problem: Motor can be damaged Solution: Always set it to “Cover”
❌ Wrong Wiring
Problem: Roller shutters move in the wrong direction Solution: Correction possible in software
❌ Leaving the Cloud Enabled
Problem: Dependency on manufacturer servers Solution: Deliberately disable the cloud
❌ Skipping Calibration
Problem: No precise positioning Solution: Run the calibration sequence
The Video Shows Everything Live
In the video you’ll see:
- ✅ Hardware comparison of various Shelly models
- ✅ Wiring diagram explained in detail
- ✅ Software setup step by step
- ✅ Home Assistant integration live
- ✅ Calibration in action
- ✅ Practical tips from my own installation
What’s Next: Even More Smart Home
More Shelly Use Cases:
- Heating control (dedicated video available)
- Light control with dimming
- Garage door automation
Home Assistant Blind Features:
- Complex automations (upcoming video)
- Time-based schedules
- Weather-dependent control
Share Your Experience
Let me know in the comments:
- How do you currently control your roller shutters?
- Do you already have experience with Shelly?
- What automation ideas do you have?
Make sure to watch the video – it shows every step live and gives you all the important details for a safe installation!
